Software solutions for evaluation and visualization of laser ablation inductively coupled plasma mass spectrometry imaging (LA-ICP-MSI) data: a short overview

Ralf WeiskirchenEmail author View ORCID ID profile,
Sabine Weiskirchen,
Philipp Kim and
Robert WinklerEmail author

Journal of Cheminformatics201911:16

https://doi.org/10.1186/s13321-019-0338-7

Received: 20 November 2018
Accepted: 9 February 2019
Published: 18 February 2019

Abstract

Mass spectrometry imaging (MSI) using laser ablation (LA) inductively coupled plasma (ICP) is an innovative and exciting methodology to perform highly sensitive elemental analyses. LA-ICP-MSI of metals, trace elements or isotopes in tissues has been applied to a range of biological samples. Several LA-ICP-MSI studies have shown that metals have a highly compartmentalized distribution in some organs, which might be altered in consequence of genetic diseases, intoxication, or malnutrition. Although metal imaging by LA-ICP-MSI is an established methodology, potential pitfalls in the determination of metal concentrations might result from erroneous calibration, standardization, and normalization. In addition, for simple display of final imaging results, most LA-ICP-MSI users prefer to process their measurements by commercial processing software. Such programs typically visualize the regional metal differences in colorful and vivid imaging maps, but might not represent the actual signal densities correctly. There is a great abundance of such MSI data processing programs available differing in quality, usability, integrated features, workflow, reliability, system requirements, speed of data processing, and price. Some software packages contain a multitude of features which are superfluous for most users. In contrast, often only few data formats are used, in case of commercial programs even only the instrument provider’s own raw data format. Therefore, first time and average users are often confused and helpless in choosing the correct software for processing their data. Here we have briefly summarized software packages, data routines, macros, programming tools, scripts, algorithms, or self-written patches and updates for existing programs presently in use for mining LA-ICP-MSI data.
